Mazak - Variaxis i-700DK-MIL-MAZ-2020-00001

Additional Equipment

• - Knoll Chip Conveyor Hinge Type 640 5-1 (#073978) / Knoll Filter System KF200 1250 / Magnetic Conveyor / Pump "Cover Coolant" 100 L/min @ 2 Bar / High Pressure Pump 31 L/min @ 70 Bar / Pump "Flood Coolant" 40 L/min @ 5 Bar / Electric Switch Cabinet / Coolant Gun

Additional Information

Machine Benefits

• Technical Machine Benefits:
  • - Spindle speed: 18000 rpm
  • - Axes: 5/ tool magazine: 40 tool magazine / touch sensor: rmp60 radio type/ smooth synchronizer tapping / auto pecking cycle with load detection fitool center point control/simult 5axes / fitool radius compensation / 5 axis eia dynamic compensation 2 (included 1) 3-d coordinate conversion / b1g00 slope constant / ethernet operation function / cylindrical & polar coord interpolation(a) / signal tower (3 colors lights, square)/ workpiece air blast / interface for coolant system (europe) / prep. For chip conveyor hinge/steel
  • - Axis movement: x-axis stroke (saddle right/left movement): 630 mm / y-axis stroke (column back/forth movement): 600 mm / z-axis stroke (spindle up/down movement): 600 mm / a-axis (table tilt travel amount/indexing 0. 0001°): -120° to +30° (axis control) / c-axis (table rotation/travel amount/indexing 0. 0001°): ±360° (axis control)
  • - Maximum table load (evenly distributed): 700 kg
  • - Table diameter (single table): 700 mm / table width (single table): 500 mm
