➤ Used Hyundai HIT-200C For Sale | gindumac.com

Show in original language

Horizontal turning machine manufactured in 2003. This Hyundai HIT-200C features a maximum turning diameter of 340 mm and a turning length of 420 mm. It is equipped with a Siemens Sinumerik CNC control and has an X-axis travel of 240 mm and Z-axis travel of 430 mm. If you are looking to get high-quality turning capabilities, consider the Hyundai HIT-200C machine we have for sale. Contact us for further details.

Overview

brand: Hyundai
year: 2003
MODEL: HIT-200C
application type: Turning
Location: Poland
machine type: Horizontal Turning Machine
control unit brand: SIEMENS

Technical Information - Hyundai HIT-200C

Control Unit

Control Brand: SIEMENS
Control Model: Sinumerik

Dimensions

Machine Weight: 4500 kg

Movement

Number of Axes: 2
X-axis Travel: 240 mm
Z-axis Travel: 430 mm

Technical Specification

Counter Spindle: No
Driven Tools: No

Additional Information

Maximum turning diameter: 340 mm
Maximum turning length: 420 mm
Spindle nose: A2-8
Spindle bore: 80 mm
Hydraulic chuck: 10"
Machine condition/accuracy: very rigid and dimensionally stable construction; capable of maintaining IT6 tolerance class

Additional equipment

Optional automation package:
- FANUC industrial robot
- ROBOTOWER loading and finished-part unloading station
- Set of grippers
- Operating manuals
- CE documentation
Note: Feeder/robot reported in very good condition; complete production cell suitable for serial production (e.g., batches of 500 parts or more)

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
