DMG MORI CLX750 V4
DMG MORI - CLX750 V4
2021
£ 159,950
Do you have further questions? Contact us.
Borja Garcia
+34 679 019 350
b.garcia@gindumac.com
- GINDUMAC
- Products
- Machine Tools
- DMG MORI CLX750 V4 Lathe
This DMG MORI CLX750 V4 Lathe was manufactured in the year 2021 and has 707 production hours, of which 175 are spindle hours. It is equipped with a DMG MORI SLIMline® Operate on SIEMENS multi-touch control unit. The machine has a spindle speed of 2000 rpm.
Overview
- brand: DMG MORI
- year: 2021
- MODEL: CLX750 V4
- production hours: 707
- application type: Turning
- Location: United Kingdom
- machine type: Lathe
- availability: Immediately
- control unit brand: DMG MORI SLIMline® Operate on SIEMENS
- GINDUMAC ID: GB-TUR-DMG-2021-00001
Technical Information
Control Unit
- Brand: DMG MORI SLIMline® Operate on SIEMENS
- Model: multi-touch control
Main drive
- Spindle speed range: 2000 1/MIN
- Spindle motor power: 36 / 46 kW
Movement
- X-AXIS Movement: 435 mm
- Y-AXIS Movement: 160 mm
- Z-AXIS Movement: 1300 mm
Additional Information
- Technical Machine Benefits:
- - Tool turret: 12-station servo turret vdi 50 with 12 driven tool stations
- - Bar passage: hydraulic partial hollow clamping cylinder - 127 mm dia
- - Tailstock: hydraulic tailstock controlled by foot pedals and m functions
- - Handwheel: electronic handwheel
- - Tool setter: tool pre-setting probe (manual)
- - Conveyor: chip conveyor instead of chip tank
- - Status: light 4-colour signal lamp
- - Chuck - main spindle: hydraulic 3-jaw chuck, d 400 mm
- - Spray gun: coolant spray gun, 5 bar
- - High pressure coolant: 5-20 bar (adjustable) - double cartridge filter
- Qualitative Machine Benefits:
- - Oil / mist separator: filtermist fx4002 mist extraction unit
- - Tool holder package: 6 x static tools & 3 x driven tools
- - Software option: technology cycle alternating speed (turning)
- - Software option: technology cycle easy tool monitoring 2. 0
- - 3d model: 3d data model in step
Machine Benefits
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
