Front view of CHARMILLES ROBOFORM 350 machine

Thank you for your visit

This machine was recently sold. Take a look at similar options or get in touch with us directly.

Browse all similar machines

Browse similar machines

CHARMILLES ROBOFORM 350

Photo Gallery

CHARMILLES - ROBOFORM 350ES-EDM-CHA-2007-00001

Sold

Do you have further questions? Contact us.

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used CHARMILLES ROBOFORM 350 For Sale | gindumac.com

Show in original language

This 3-axis CHARMILLES ROBOFORM 350 was manufactured in 2007. It features a CNC control with a graphical user interface and optional C-axis for tool changes. The machine accommodates workpieces up to 500 kg, with a dielectric system capacity of around 400 liters. If you are looking to get high-quality die-sinking capabilities, consider the CHARMILLES ROBOFORM 350 machine we have for sale. Contact us for more information about this machine.

Overview

brand: CHARMILLES
year: 2007
MODEL: ROBOFORM 350
application type: EDM
Location: Spain
machine type: Die-Sinking EDM Machine

Technical Information - CHARMILLES ROBOFORM 350

Dimensions

Machine Depth: 1750 mm
Machine Height: 2300 mm
Machine Weight: 2300 kg

Movement

Number of Axes: 3
X-axis Travel: 350 mm
Y-axis Travel: 250 mm
Z-axis Travel: 300 mm

Additional Information

Additional equipment

Tool Changer (C-axis): Optional – can support automatic tool changers
Dielectric System Capacity: Approx. 400 liters

Machine Benefits

Technical Machine Benefits

Worktank dimensions (lxwxh): 790 x 530 x 350 mm
Max. Workpiece dimensions (lxwxh): 790 x 530 x 215 mm
Table dimensions (lxw): 500 x 400 mm
Distance from table to chuck: 170 to 470 mm
Tool electrode weight (max. ): 50 kg
Cnc control: charmilles cnc with graphical user interface

Extra Information

Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
