This 6-axis Universal Robots UR10 was manufactured in 2021, featuring a payload capacity of 10 kg and a reach of 1300 mm. It offers six rotating joints, operates within an ambient temperature range of 0−50°C, and has a noise level of 72dB(A). The robot can be mounted in any position and is IP54 rated, suitable for ISO Class 5 cleanrooms. If you are looking to get high-quality automation capabilities consider the Universal Robots UR10 machine we have for sale. Contact us for more information.
Overview
- brand: Universal Robots
- year: 2021
- MODEL: UR10
- application type: Robotics
- Location: Germany
- machine type: Robot Arm
Technical Information - Universal Robots UR10
Dimensions
- Machine Weight: 28.9 kg
Movement
- Number of Axes: 6
Additional Information
Reach: 1300 mm / 51.2 in
Degrees of freedom: 6 rotating joints
Repeatability: ±0.1 mm / ±0.0039 in (4 mils)
Ambient temperature range: 0–50 °C
Noise: 72 dB(A)
Robot mounting: Any
IP classification: IP54
ISO cleanroom class: 5
Footprint: Ø190 mm
Materials: Aluminium, PP plastics
Tool connector type: M8
Cable length: 6 m / 236 in
I/O ports: 2 digital in, 2 digital out, 2 analog in, 0 analog out
I/O power supply (tool): 12 V / 24 V, 600 mA
Joint ranges and max speeds (as provided)
Base: ±360°, ±120°/s
Shoulder: ±360°, ±120°/s
Elbow: ±360°, ±180°/s
Wrist 1: ±360°, ±180°/s
Wrist 2: ±360°, ±180°/s
Wrist 3: ±360°, ±180°/s
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
