Front view of Trumpf Trumatic L 4030 machine

Thank you for your visit

This machine was recently sold. Take a look at similar options or get in touch with us directly.

Browse all similar machines

Browse similar machines

TRUMPF Trumatic L 4030

Photo Gallery

TRUMPF - Trumatic L 4030PL-LAS-TRU-1996-00001

Sold

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Sheet Metal Machinery
Trumpf Trumatic L 4030 Laser Cutting Machine

Show in original language

This Trumpf Trumatic L 4030 Laser Cutting Machine was made in the year 1996 in Germany. It is equipped with a Bosch control unit. This machine is capable of cutting steel sheets up to 15 mm of thickness.

Overview

brand: TRUMPF
year: 1996
MODEL: Trumatic L 4030
production hours: 27165
application type: Cutting
Location: Poland
machine type: CO2 Laser Cutting Machine
control unit brand: BOSCH

Technical Information - TRUMPF Trumatic L 4030

General Data

Measurements width: 11500 mm
Measurements depth: 6000 mm
Measurements height: 2000 mm
Machine weight: 16000 kg

Control Unit

Brand: BOSCH

Movement

X-AXIS Movement: 4150 mm
Y-AXIS Movement: 2140 mm
Z-AXIS Movement: 117 mm

Max Material thickness

Steel: 15 mm

Media

Main electronic connection: 400V / 50Hz
Power consumption: 71 kVA
Internal cooling: Yes

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Big size of table
Qualitative Machine Benefits:
- - Very good technical condition, a small number of working hours

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
