This 3-axis MILLTRONICS RH 20 vertical machining centre was manufactured in 2014. It features a substantial table size of 1,372 mm x 508 mm and impressive X-axis travel of 1,016 mm. The machine is equipped with a 24-station automatic tool changer and a spindle speed of 10,000 RPM. If you are looking to get high-quality machining capabilities, consider the MILLTRONICS RH 20 machine we have for sale. Contact us for further details.
Overview
- brand: MILLTRONICS
- year: 2014
- MODEL: RH 20
- application type: Milling
- Location: Spain
- machine type: Vertical Machining Centre
- control unit brand:
Technical Information - MILLTRONICS RH 20
Dimensions
- Machine Weight: 6125 kg
Movement
- Number of Axes: 3
- X-axis Travel: 1016 mm
- Y-axis Travel: 559 mm
- Z-axis Travel: 610 mm
Technical Specification
- Spindle Power: 18 kW
- Spindle Speed: 10000 RPM
- Taper Size: ISO 40
Additional Information
Table size: 1,372 mm x 508 mm (54" x 20")
Spindle nose to table: 102–711 mm (4"–28")
Spindle torque: 122 N·m (90 ft·lb)
Transmission: 2-speed torque range
Automatic tool changer: 24-station twin arm
Max tool diameter: 75 mm (3")
Max tool length: 300 mm (11.8")
Rapid traverse (X/Y/Z): 24/24/15 m/min (945/945/600 ipm)
Control system: Milltronics CNC with 15" color LCD
Power required: 30 kVA / 80 A
Voltage: 208–240 V, 3-phase
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
