Kitamura Mycenter HX250

Photo Gallery

Kitamura - Mycenter HX250ES-MIL-KIT-1999-00001

Sold

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used Kitamura Mycenter HX250 Horizontal Machining Center

Show in original language

This Kitamura Mycenter HX250 Horizontal Machining Center was manufactured in Japan in 1999. This 3 axis machine incorporates a table of 254 x 254 mm and a 8000 rpm spindle. In the past, it has mainly worked with steel in the production of machined components.

Overview

brand: Kitamura
year: 1999
MODEL: Mycenter HX250
application type: Milling
Location: Spain
machine type: Horizontal Machining Centre

Technical Information - Kitamura Mycenter HX250

Dimensions

Machine Depth: 2950 mm
Machine Height: 2470 mm
Machine Weight: 4500 kg
Table Length: 254 mm
Table Width: 254 mm

Movement

B-axis Max: 360°
B-axis Min: 0.001°
X-axis Travel: 305 mm
Y-axis Travel: 305 mm
Z-axis Travel: 330 mm

Technical Specification

Max. Tool Weight: 2 kg
Spindle Speed: 8000 RPM
Tool Stations: 24

Additional Information

Additional equipment

Filtermist FX2000
2 x Pallets

Machine Benefits

Qualitative Machine Benefits

Well maintained machine
Change of spindle synchronous belt
Change of screen to tft
Repair of front button panel
Repair and cleaning of ducts
Calibration and adjustment of tool magazine
Repair of leaks in the double pallet table

Technical Machine Benefits

Compact footprint

Machine History

End product

Machined components

Material type

Steel

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
