HAITIAN - ZE1900 RO-INJ-HAI-2019-00002

Name: HAITIAN ZE1900
Brand: HAITIAN
SKU: RO-INJ-HAI-2019-00002
Price: 63282 GBP
Availability: InStock

£ 63,282

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Plastics Processing Machinery
➤ Used HAITIAN ZE1900 For Sale | gindumac.com

Show in original language

This HAITIAN ZE1900 was manufactured in 2019. It features a clamping force of 1900 kN, a maximum injection volume of 412 cm³, and a screw diameter of 50 mm. The machine includes a robot interface (Euromap 67) and is still in production with excellent condition. If you are looking to get high-quality injection molding capabilities, consider the HAITIAN ZE1900 machine we have for sale. Contact us for more information about this machine.

Overview

brand: HAITIAN
year: 2019
MODEL: ZE1900
production hours: 20270
application type: Injection Moulding
Location: Romania
machine type: Electrical Injection Moulding Machine

Technical Information - HAITIAN ZE1900

Dimensions

Machine Height: 2160 mm
Machine Length: 5871 mm
Machine Weight: 9300 kg

Technical Specification

Clamping Force: 1900 kN
Screw Diameter: 50 mm

Additional Information

Maximum injection volume: 412 cm³
Mold height (min/max): 200 / 550 mm
Opening stroke: 1,020 mm
Platen dimensions (W × L): 790 × 840 mm
Tie-bar distance: 570 × 520 mm
Motor power: 45 kW
Heater power: 20.2 kW
Electrical connection pins: 32
Injection nozzle radius (tip): R10
Centering ring diameter: 160 mm
Operating hours: 20,207 h
Condition: Excellent
Status: In production

Additional equipment

Robot (included)
Robot interface: Euromap 67

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
