EMAG - VTC 250 Twin HU-TUR-EMA-2015-00001

£ 48,730
gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer

Do you have further questions? Contact us.

sales contact

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

whatsapp
Click to chat on WhatsApp
Show in original language

This EMAG VTC 250 Twin was manufactured in 2015. A robust vertical turning machine featuring a MINERALIT base, it handles workpieces up to 140 mm in diameter and 630 mm in length, weighing up to 20 kg. Integrated with an EMAG pick-up system and dual turrets, each with 11 tool stations. Maximum spindle speed reaches 5000 rpm, driven by a 29 kW power unit. Contact us for more information about this machine.

Overview

  • brand: EMAG
  • year: 2015
  • MODEL: VTC 250 Twin
  • application type: Turning
  • Location: Hungary
  • machine type: Vertical Turning Machine

Technical Information - EMAG VTC 250 Twin

Dimensions

  • Machine Height: 3900 mm
  • Machine Length: 3100 mm
  • Machine Weight: 14000 kg

Movement

  • Number of Axes: 2
  • X-axis Travel: 300 mm
  • Z-axis Travel: 740 mm

Technical Specification

  • Spindle Speed: 5000 RPM

Additional Information

  • Machine base: MINERALIT

  • Max workpiece diameter: 140 mm

  • Max workpiece length: 630 mm

  • Max workpiece weight: 20 kg

  • Number of turrets: 2

  • Tool stations per turret: 11

  • Tool shank diameter: 40 mm

  • Rapid traverse (X/Z): 30 m/min / 40 m/min

  • Feed force (X/Z): 9.4 kN / 10 kN

  • Ball screw diameters (X/Z): 32 mm / 40 mm

  • Spindle nose: DIN 55026-A6

  • Front bearing diameter: 110 mm

  • Drive (100% duty): 29 kW / 200 Nm / 1400 rpm (speed at nominal power)

  • Loading time: 4–5 s

  • Chip-to-chip: 6–7 s

Additional equipment

  • Integrated EMAG pick-up system (automation)

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
