This Peddinghaus Avenger MDL1000B Drilling machine was manufactured in the year 2005 in the United States. It is equipped with a Siemens Sinumerik 840D control unit. The machine has a table of 1830 x 1000 mm, and includes a Rush 250A Drill Grinder and a Selection of Drills as additional equipment.
Overview
- brand: Peddinghaus
- year: 2005
- MODEL: Avenger MDL1000B
- application type: Other Machine Tools
- Location: Ireland
- machine type: Drilling Machine (Metal)
- control unit brand: SIEMENS
Technical Information - Peddinghaus Avenger MDL1000B
General Data
- Measurements width: 2050 mm
- Measurements depth: 3500 mm
- Measurements height: 2560 mm
Control Unit
- Model: Sinumerik 840D
- CNC main language: English
- Brand: SIEMENS
Movement
- X-AXIS Movement: 1830 mm
- Y-AXIS Movement: 330 mm
Workpiece
- Workpiece x: 1830 mm
- Workpiece y: 1000 mm
Table
- Outer length: 1830 mm
- Outer width: 1000 mm
Tools
- Max tool diameter: 50 mm
Media
- Main electronic connection: 400 V
- Power consumption: 14,9 kW
Additional Information
Additional equipment
- Rush 250A Drill Grinder
- Selection of Drills
Machine Benefits
Qualitative Machine Benefits
- Max speed y-axis: 120 ft/min (37m/min. )
- Spindle power: 13 3/4hp (10kw)
- Drilling feed rate: 2" – 10" per min (50-254mm/min) infinitely variable
Technical Machine Benefits
- New machine control in 2017
- Includes a rush 250a drill grinder worth €6,000
- Table: 60 ft
- Average output: 200 to 400 holes per hour
- Max beam size: 60ft x 40" (18. 3m x 1000mm)
- Max beam weight: 730lbs/ft (1088kg/m)
- Min drill diameter: 1/4" (6. 5mm)
- Max drill diameter: 2" (50mm)
- Max thickness: up to 10" (250mm)
- Max speed x-axis: 120 ft/min (37m/min. )
Machine History
Industries
Structural steel industry
End product
Structural steel beams
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
