This MIKRON BTM 2000 surface grinding machine was manufactured in 1994. It features an impressive X-axis travel of 2,000 mm, Y-axis travel of 800 mm, and Z-axis travel of 1,000 mm. The machine has a maximum table load of 3,500 kg and a spindle speed of up to 4,000 rpm. If you are looking to get high-quality surface grinding capabilities, consider the MIKRON BTM 2000 machine we have for sale. Contact us for further details.

Overview

  • brand: MIKRON
  • year: 1994
  • MODEL: BTM 2000
  • application type: Grinding
  • Location: Germany
  • machine type: Surface Grinding Machine
  • control unit brand: HEIDENHAIN

Technical Information - MIKRON BTM 2000

Control Unit

  • Control Brand: HEIDENHAIN
  • Control Model: TNC 407

Movement

  • Number of Axes: 3
  • X-axis Travel: 2000 mm
  • Y-axis Travel: 800 mm
  • Z-axis Travel: 1000 mm

Additional Information

- Not fully functional; error message "Grober Positionierfehler" (Gross positioning error);

- Electronic Handwheel: Heidenhain HR 330

- Maximum Table Load: 3,500 kg

- Rapid Traverse (X/Y/Z): 15 m/min each

- Milling Head: Manual universal milling head

- Spindle Speed: Up to 4,000 rpm (min⁻¹)

- Tool Taper / Holder: ISO 40 according to DIN 2080

- Linear Measuring System: Direct Heidenhain LS 106 C linear scales in X, Y, and Z

- Drive Technology: Siemens SIMODRIVE 611

- Working Area Enclosure: Sliding doors and strip curtain / lamellar splash guard

- Cooling / Auxiliary: Separate cooling unit / aggregate

- Maintenance History: Y/Z-slides overhauled by a specialized company approx. six years ago

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.

** The default scope of delivery includes the machine only. Accessories and peripheral equipment will be confirmed through binding agreements during the purchasing process.
