JUNKER - QUICKPOINT 5002/10 ES-GRI-JUN-2002-00001

£ 95,800
gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer

Do you have further questions? Contact us.

sales contact

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

whatsapp
Click to chat on WhatsApp
Show in original language

This 3-axis JUNKER QUICKPOINT 5002/10 was manufactured in 2002. It features a Siemens control system, Marposs measuring, and CNC-controlled Z-axis and grinding spindle head. With a grinding length of 1000 mm and a diameter up to 280 mm, it's ideal for precision surface grinding. Consider the opportunity to buy this JUNKER QUICKPOINT 5002/10 surface grinding machine. Contact us for more information about this machine.

Overview

  • brand: JUNKER
  • year: 2002
  • MODEL: QUICKPOINT 5002/10
  • application type: Grinding
  • Location: Spain
  • machine type: Surface Grinding Machine

Technical Information - JUNKER QUICKPOINT 5002/10

Dimensions

  • Machine Weight: 11000 kg

Additional Information

  • Grinding length between centers: 1000 mm

  • Grinding diameter: 280 mm

  • Workpiece diameter range: 20–80 mm

  • Turning diameter at grinding wheel height: 70 mm

  • Workhead spindle dimensions: 100 × 400 mm

  • Tailstock adjustment: Chain driven

  • Part clamping: Hydraulic

  • Axes:

    • Z-axis: CNC controlled

    • Grinding spindle head (X-axis): CNC controlled

  • Grinding spindle dimensions: 180 × 400 mm

  • Standard flange diameter: 127 mm

  • Main spindle motor power: 24 kW

  • Grinding wheel dimensions: 400 × 127 mm

  • Peripheral speed: 90 m/s

Additional equipment

  • Measuring system: Marposs

  • Balancing system: Electronic

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
