This 3-axis Hurco VMX84i was manufactured in 2015. It features a WinMax control system, a table size of 2185 × 865 mm, and a maximum table load of 2270 kg. The machine offers a travel range of 2135/865/762 mm and a spindle speed up to 12000 RPM. It includes a 40-position automatic tool changer and through-spindle coolant. If you are looking to get high-quality milling capabilities, consider the Hurco VMX84i machine we have for sale. Contact us for more information.
Overview
- brand: Hurco
- year: 2015
- MODEL: VMX84i
- application type: Milling
- Location: Hungary
- machine type: Vertical Machining Centre
- Available from: 09/01/2026
Technical Information - Hurco VMX84i
Dimensions
- Machine Weight: 17000 kg
- Table Load: 2270 kg
Movement
- Number of Axes: 3
- X-axis Travel: 2135 mm
- Y-axis Travel: 865 mm
- Z-axis Travel: 762 mm
Technical Specification
- Max. Tool Weight: 7 kg
- Spindle Power: 18 kW
- Spindle Speed: 12000 RPM
- Taper Size: SK 40
Additional Information
Control: WinMax
Table working surface (W x D): 2185 x 865 mm
Spindle nose to table: 127 – 887 mm
T-slots (DIN 650): 8 slots, 18 mm, 125 mm spacing
Max spindle torque: 239 Nm (SK40)
Rapid traverse (X/Y/Z): 18 / 18 / 13.5 m/min
Automatic tool changer: 40 stations (SK40)
Max tool diameter: 75 mm (SK40)
Max tool length: 300 mm
Through-spindle coolant: yes
Workpiece probing: yes
Tool wear measurement: none
Coolant tank capacity: 867 l
Required floor space (with open doors, control, and chip conveyor): 7574 x 4450 x 3310 mm
Additional equipment
Scraper-type chip conveyor (standard)
Workpiece probing system
