GRENZEBACH - FSW Machine DSM 2400 SI-OTH-GRE-2019-00001

Name: GRENZEBACH FSW Machine DSM 2400
Brand: GRENZEBACH
SKU: SI-OTH-GRE-2019-00001
Price: 76070 GBP
Availability: InStock

£ 76,070

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Do you have further questions? Contact us.

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used GRENZEBACH FSW Machine DSM 2400 | Machine Tool

Show in original language

This 3-axis GRENZEBACH FSW Machine DSM 2400 was manufactured in 2019. It features a working area with X-axis travel of 1,400 mm, Y-axis travel of 1,000 mm, and Z-axis travel of 600 mm. The machine has a maximum spindle speed of 5,000 rpm and a total weight of 23,250 kg. If you are looking to get high-quality friction stir welding capabilities, consider the GRENZEBACH FSW Machine DSM 2400 we have for sale. Contact us for further details.

Overview

brand: GRENZEBACH
year: 2019
MODEL: FSW Machine DSM 2400
application type: Other Machine Tools
Location: Slovenia
machine type: Machine Tool

Technical Information - GRENZEBACH FSW Machine DSM 2400

Dimensions

Machine Height: 3444 mm
Machine Length: 4923 mm
Machine Weight: 23250 kg
Machine Width: 3300 mm

Movement

Number of Axes: 3
X-axis Travel: 1400 mm
Y-axis Travel: 1000 mm
Z-axis Travel: 600 mm

Technical Specification

Spindle Speed: 5000 RPM

Additional Information

Weights:
- Basic machine: 17,750 kg
- Welding fixture: 4,200 kg
Electrical:
- Power supply: 400 V / 50 Hz / 3PH+N+PE
- Max. power consumption: 16 kW
Pneumatics:
- Minimum pressure: 5 bar
- Air consumption: 48 m³/h
Speeds:
- Max. rapid traverse: 20 m/min
- Max. process speed: 1.5 m/min
Process forces:
- X/Y: 2.6 kN
- Z: 10 kN
Noise level: 70–80 dB(A)

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.

** The default scope of delivery includes the machine only. Accessories and peripheral equipment will be confirmed through binding agreements during the purchasing process.
