DOOSAN - dnm 5700SI-MIL-DOO-2021-00002

Name: DOOSAN dnm 5700
Brand: DOOSAN
SKU: SI-MIL-DOO-2021-00002
Price: 66984 GBP
Availability: InStock

£ 66,984

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Do you have further questions? Contact us.

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used DOOSAN dnm 5700 For Sale | gindumac.com

Show in original language

This 4-axis DOOSAN DNM 5700 was manufactured in 2021. It features an impressive X-axis travel of 1,050 mm, Y-axis travel of 570 mm, and Z-axis travel of 510 mm. The machine is equipped with a 30-position tool magazine and a spindle speed of 12,000 rpm. If you are looking to get high-quality machining capabilities, consider the DOOSAN DNM 5700 vertical machining centre we have for sale. Contact us for further details.

Overview

brand: DOOSAN
year: 2021
MODEL: dnm 5700
application type: Milling
Location: Slovenia
machine type: Vertical Machining Centre
control unit brand: FANUC

Technical Information - DOOSAN dnm 5700

Control Unit

Control Brand: FANUC

Movement

Number of Axes: 4
X-axis Travel: 1050 mm
Y-axis Travel: 570 mm
Z-axis Travel: 510 mm

Technical Specification

Spindle Power: 18.5 kW
Spindle Speed: 12000 RPM
Taper Size: BT 40
Tool Stations: 30

Additional Information

Condition: Excellent (used)
Functionality: Fully functional
15" display
2 MB part program storage / 1,000 programs
Rapid traverse X-axis: 36 m/min
Rapid traverse Y-axis: 36 m/min
Rapid traverse Z-axis: 30 m/min
Spindle torque: 118 Nm
Through-spindle coolant: 12 bar
Ethernet connection
Ball screw nut cooling
Tool breakage detection in magazine
Automatic doors
Standard-height column
Hydraulic system 3A + 1B
Seat air check
Coolant level sensor

Additional equipment

Robot interface
4th axis
Hiwin RCV 250 rotary table
HIWIN RTS 250 support
4th-axis fixture support hydraulic
LNS MH500 chip conveyor
Oil skimmer, belt type
Coolant gun
Mist collector interface

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.

** The default scope of delivery includes the machine only. Accessories and peripheral equipment will be confirmed through binding agreements during the purchasing process.
